Rockfon Acoustic Ceiling Tiles

Description

Rockfon Acoustic Ceiling Tiles

Hush City Soundproofing carries 6 different models of Rockfon Acoustic Ceiling Tiles:

Rockfon Sonar –

Edges SQ, SLN, SLT, DMT, SLP, SCD, CDX (see below for diagram)
Dimensions
Width (min. – max.)
Length (min. – max.)
1′ 8″ – 4′
2′ – 8′
Color White
Texture Lightly textured
Light reflection 0.85
NRC 0.70 – 0.95
CAC 22 – 25
AC 190
Fire class A
Fire performance
Flame Spread Index : 10, Smoke Developed Index : 5

Rockfon Sonar dB –

Edges SQ, SLN, SLT, SLP (see below for diagram)
Dimensions
Width (min. – max.)
Length (min. – max.)
2′
2′
Color White
Texture Lightly textured
Light reflection 0.85
NRC 0.85
CAC 33 – 43
AC 170 – 190
Fire class A
Fire performance
Flame Spread Index : 10-15, Smoke Developed Index : 5

Rockfon Alaska –

Edges SQ, SLN, SLT, DMT, SCD, CDX (see below for diagram)
Dimensions
Width (min. – max.)
Length (min. – max.)
2′
2′ – 6′
Color White
Texture smooth
Light reflection 0.86
NRC 0.70 – 0.90
CAC 22
AC 180
Fire class A
Fire performance
Flame Spread Index : 5, Smoke Developed Index : 0

Rockfon Alsak dB –

Edges SQ, SLN, SLT (see below for diagram)
Dimensions
Width (min. – max.)
Length (min. – max.)
2′
2′ – 4′
Color White
Texture smooth
Light reflection 0.86
NRC 0.85
CAC 35
AC 180
Fire class A
Fire performance Flame Spread Index : 10-15, Smoke Developed Index : 5

Rockfon Artic –

Edges SQ, SL, SLN (see below for diagram)
Dimensions
Width (min. – max.)
Length (min. – max.)
1′ 8″ – 2′
2′ – 5′
Color White
Texture smooth
Light reflection 0.85
NRC 0.75
CAC 23
AC
Fire class A
Fire performance Flame Spread Index : 5, Smoke Developed Index : 0

Rockfon Pacific –

Edges SQ, SLN, SL
Dimensions
Width (min. – max.)
Length (min. – max.)
2′
2′ – 4′
Color White
Texture smooth
Light reflection 0.85
NRC 0.60
CAC
AC
Fire class A
Fire performance Flame Spread Index : 5, Smoke Developed Index : 0

Panel Edge Diagram –

 Square Lay-in (SQ)

 Square Tegular Narrow (SLN)

 Angled Tegular (SLT)

 Direct Mount (DMT)

 Shiplap (SLP)

 Semi-Concealed (SCD)

 Concealed-X (CDX)
